FLEET V series 500001213/G
APPENDIX A - GAS DATA
F85V F100V
F125V F150V
Gas Inlet Connection Pipe Thread Size
R ¾” R ¾” R 1” R 1”
Nominal Inlet Pressure Nat Gas -mbar
20
Maximum Inlet Pressure Nat Gas -mbar 25
Gas Pressure Switch Setting Nat Gas -mbar
Gas Flow Rate (max. per module) Nat Gas -m
3
/h 8.25 9.7 11.7 14.6
Target CO
2
% at High / Low fire Nat Gas ±0.25%
9.0
12.5
GENERAL DATA
BOILER MODEL
F40V-80
F40V-120
F50V-100
F50-V150
Boiler Input (maximum) - kW (Gross) 82.0 123.0 102.6 153.9
Boiler Input (maximum) - kW (Nett) 73.8 110.7 92.4 138.6
Boiler Output kW (maximum) condensing 50/30°C - kW 80 120 100 150
Boiler Output kW (maximum) non condensing 80/60°C - kW 72.2 108.3 90.2 135.3
Boiler Module Output (minimum) 80/60°C - kW 7.2 7.2 9.0 9.0
F60V-120
F60V-180 F70V-140 F70V-210
Boiler Input (maximum) - kW (Gross) 123.0 184.5 143.6 215.4
Boiler Input (maximum) - kW (Nett) 110.8 166.2 129.4 194.1
Boiler Output kW (maximum) condensing 50/30°C - kW 120 180 140 210
Boiler Output kW (maximum) non condensing 80/60°C - kW 108.2 162.3 126.4 189.6
Boiler Output (minimum) 80/60°C - kW 10.8 10.8 12.6 12.6
GAS DATA - per boiler module
F40V F50V
F60V F70V
Gas Inlet Connection Pipe Thread Size
R ¾” R ¾” R ¾” R ¾”
Nominal Inlet Pressure Nat Gas -mbar
20
Maximum Inlet Pressure Nat Gas -mbar 25
Gas Pressure Switch Setting Nat Gas -mbar
12.5
Gas Flow Rate (max. per module) Nat Gas -m
3
/h
3.9 4.8 5.8 6.8
Target CO
2
% at High / Low fire Nat Gas ±0.25%
9.0
Figure A1– Gas data
F85V-170
F85V-255 F100V-200 F100V-300
Boiler Input (maximum) - kW (Gross) 174.4 261.6 205.2 307.8
Boiler Input (maximum) - kW (Nett) 157.0 235.5 184.8 277.2
Boiler Output kW (maximum) condensing 50/30°C - kW 170 255 200 300
Boiler Output kW (maximum) non condensing 80/60°C - kW 153.4 230.1 180.6 270.9
Boiler Output (minimum) 80/60°C - kW 15.3 15.3 17.9 17.9
F125V-250
F125V-375 F150V-300 F150V-450
Boiler Input (maximum) - kW (Gross) 256.4 384.6 307.6 461.4
Boiler Input (maximum) - kW (Nett) 231.0 346.5 277.2 415.8
Boiler Output kW (maximum) condensing 50/30°C - kW 250 375 300 450
Boiler Output kW (maximum) non condensing 80/60°C - kW 225.6 338.4 270.8 406.2
Boiler Output (minimum) 80/60°C - kW 21.6 21.6 26.9 26.9
