HAMWORTHY HEATING LTD
3
FLEET V series
500001213/G
Figure 2.2 - Boiler Packaged Dimensions
Delivery Verification
When taking delivery please ensure that you have received the correct number of boilers and flue collector
manifolds to fulfil your order. If any item is missing please contact our after sales service team. Please provide
details of your order such as order number and contract number as well as a detailed description of the missing
item.
Frame Set and Pipe work Header Kits
Where pipe work kits are supplied, these are packaged separately from the boilers. All ancillary items such as
isolation valves and boiler make-up connectors are factory fitted and tested The whole is shrink wrapped for security and
basic protection. Refer to Kit instructions 500005134 for specific information.
Model H mm W mm D mm Weight (kg)
F40V-80 1445 720 720 213
F50V-100 1445 720 720 213
F60V-120 1445 720 720 237
F70V-140 1445 720 720 237
F85V-170 1445 720 720 270
F100V-200 1445 720 720 270
F125V-250 1445 720 820 303
F150V-300 1445 720 820 329
F40V-120 2050 720 720 325
F50V-150 2050 720 720 325
F60V-180 2050 720 720 344
F70V-210 2050 720 720 344
F85V-255 2050 720 720 395
F100V-300 2050 720 720 395
F125V-375 2050 720 820 444
F150V-450 2050 720 820 470
Flue manifold 900 300 300 7
