21. Mercedes Benz 38Pin Adapter
(P/N. 3001-0015)
Used for the communication with
Mercedes Benz cars equipped with 38Pin
vehicle side DLC.
Applied with C202, CLK208, E210, E124,
S140, SL129, SLK170, G463, G461.
22. Mercedes Benz 4Pin Adapter(P/N. 3001-0009)
Used for the communication with Mercedes Benz cars equipped with
8Pole or 16Pole vehicle side DLC.
(Red: Battery +, Gray: K Line,, Yellow :
Ignition check, Black: Ground)
Applied with C201, E124, S126, SL107,
G463
23. Upgrade cable
(P/N. 3000-0010)
To be connected to main data link
cable for updating your
MULTISCAN plus software by
downloading updated codes from
your PC. Refer to the related
chapter in this manual.
