Hanatech Co., Ltd.
Chapter 4
Chapter 4 - 7
C. Data Freeze
The [Data Freeze] function places the selected data stream variable on top of
the LCD screen so that the user can check and compare desired sensor
values continually without having to scroll up and down.
This is different from ‘Freeze Frame Data’ function of Generic OBD2.
1) Step One
Select a desired sensor using the [◀][▶] and the [▲][▼] keys.
2) Step Two
Press the [ENTER] key to freeze the selected sensor.
i.e., when O2 sensor and MAP sensor are selected and frozen, these
sensor values will be placed at the top of the display as below :
3) Step Three
Up to five sensors may be frozen at a time. For example, if the Injection
Time, which can be shown when scrolled down, is selected and frozen,
Injection Time value will be placed below the previously frozen O2 and MAP
sensor.
