USER MANUAL For MULTISCAN
Chapter 3 - 4
3. Vehicle battery
a. Sometimes it is necessary to put the head unit in the engine
compartment when testing OBD1 generation vehicles with the
diagnostic adapters located near the engine, such as Toyota, Mazda,
Kia, Ssangyong, BMW, Mercedes Benz, etc.
b. In case power is not supplied through the diagnostic adapter,
connect the alligator clips of the battery power cable to the battery
terminals of correct polarity. Check the red LED on the round
socket turns ON.
c. Connect the cigarette lighter power cable connector into the battery
power cable socket.
4. Power ON
MULTISCAN automatically turns on when power is supplied properly..
