Operating MULTISCAN
I. Getting Started---------------------------------
A. Head Unit
①. LCD Display
②. Key Pad (may be designed differently)
③. 12V Power Jack Connection
④. 15-pin Main DLC Cable Connection
⑤. USB Communication port
⑥. RS232C Serial Communication Port
⑦. LCD Contrast Adjustment Dial
⑧. PCMCIA slot
