B
A
D
C
E
Flip down the abduction support
1. Pull (A) out of the locked position and fl ip
down (B)
2. Release (A).
Flip up the abduction support
3. Pull (A) out of the locked position and fl ip
up (B).
4. Release (A) in the locked position.
Note!
Ensure that (B) is properly secured!
Folding back the thoracic support
1. Press (A) to fold back (B).
4.4 Reducing the seating system
in size for transportation
purposes
A. Removing the headrest, see 4.3 ‘Options/
accessories (1,3 kg)
B. Removing the seat cushion (2,5 kg)
C. Flip up the armrest
D. Folding the backrest fully forward
E. Removing the legrest or fold up footplates
Warning!
The wheelchair can be reduced in size for
transportation without a passenger. Any
components of the seating system that can
be detached easily should be removed. Store
away such components safely so that they
can not cause injury or damage, or become
damaged themselves.
