Adjustments (to be carried out by a professional) 27Sedeo Pro+
b
A
B
A
a
B
A
a
b
5.13 Abduction support
Adjust the abduction support as follows:
1. Loosen the Torx screw.
2. Adjust the part to the desired position.
3. Tighten the Torx screw.
A/a. Height adjustment.
B/b. Depth adjustment.
5.14 Thoracic support
Adjust the thoracic support as follows:
1. Loosen the Torx screw.
2. Adjust the part to the desired position.
3. Tighten the Torx screw.
A/a. Rough adjustment of width
B/b. Height adjustment
A/a. Adjustment of bracket depth
B/b. Adjustment of cushion depth
