12 Use Sedeo Pro+
B
A
1
2
A
2
1
A
B
1
2
Removing the standard legrest
1. Push (A) to the rear.
2. Swing (B) to the side.
3. Remove (B).
4.5 Setting up the seating
system following
transportation
Positioning the standard legrest
1. Place the legrest (A) in the bracket.
2. Swing the legrest inwards.
Caution!
You should hear a click when replacing the
legrest. This indicates that the legrest has
locked into place.
Positioning the backrest for use
1. Lift (A) upwards and backwards.Due to its
weight the backrest will fall into place.
2. Tighten the star knobs (B).
Warning!
Watch squeezing your fi ngers while lifting the
back.
