Adjustments (to be carried out by a professional) 15Sedeo Pro+
A
B
3
2
4
1
5
A
B
1
A
1
3
2
5.3 Backrest height
Note!
First loosen the velcro backrest fl ap from the
seat frame.
Height (1)
1. Loosen the 8 screws (A) by one turn.
2. Adjust the backrest to the desired position.
3. Tighten the 8 screws (A).
Height (2)
1. Remove the 8 screws (A, left and right).
2. Remove the 4 clamps of the backrest
cushion
3. There are extra mounting holes in the wood
of the backrest (B). Make holes in the fabric
at the desired position.
4. Mount the clamps on the backrest
5. Mount the backrest on the frame by tighten
the 8 screws (A).
5.4 Standard and manually
elevating legrest
Legrest width
1. Loosen (A) by one turn.
2. Slide (B) into the desired position.
3. Tighten (A).
