32 Technical specifi cations Sedeo Pro+
8 Technical specifi cations
8.1 CE declaration and requirements
The product is in conformity with the provisions of the Medical Devices Directive and
carries the CE mark.
The product also meets the following requirements and standards. This has been verifi ed by
independent test organizations.
1. EN 12183 (2009) Manual wheelchairs or EN 12184 (2009) Electrically powered wheelchairs.
2. ISO 7176-8 Requirements for impact, static and fatigue strength.
3. ISO 7176-9 Climatic tests for electric wheelchairs and scooters.
4. ISO 7176-16 Requirements for resistance to ignition of upholstered parts.
5. ISO 7176-19 Crash test.
6. EN-ISO 10993-5 (1999-11) Biological evaluation of medical devices.
7. EN 1021 1,2 Assessment of the ignitability of upholstered furniture. Ignition source: smouldering
cigarete/match fl ame equivalent.
8.2 Technical information
Seating system
User weight kg (st.) 160 (25.2)
Seat width mm (inch) 380 - 600 (15 - 23.6)
Seat depth mm (inch) 440 - 600 (15.7 - 23.6)
Point of gravity mm (inch) 95 (3.7)
Backrest
Backrest height mm (inch) 480 - 670 (18.9 - 26.4)
Backrest recline ° 90 - 135
Armrest
Armrest pad width mm (inch) -40 till +20 (-1.6 till +0.8)
Armrest pad height from seat frame mm (inch) 240 - 360 (9.4 - 14.2)
Armrest pad depth controller bracket side mm (inch) 95 (3.7)
Armrest pad depth non controller bracket side mm (inch) 140 (5.5)
Side support
Side cushion height mm (inch) 100 (3.9)
Central legrest
Lower leg length (with compressed seat cushion) mm (inch) 330 - 495 (13 - 19.5)
Knee angle ° 30 - 110
Ankle angle ° +20 till -40
Central calf support height (option) mm (inch) 120 (4.7)
