Handicare SEDEO PRO+ - Armrest Assembly

20 Adjustments (to be carried out by a professional) Sedeo Pro+
2
A
B
1
A
1
B
A
2
1
3
Calf pad depth
1. Unscrew (A)
2. Adjust (B) to desired depth and move (A) to
new hole.
3. Tighten (A)
5.7 Armrest assembly
Note!
Ensure that the arms are supported well,
without the shoulders being pushed upwards.
Armrest height (1)
1. Loosen (A) by one turn.
2. Adjust the armrest to the desired position.
3. Tighten (A).
Armrest height (2)
1. Turn screw A to position the armrest height
2. Loosen B by one turn
3. Adjust the armrest angle
4. Tighten (B)
