Use 9Sedeo Pro+
2
B
A
1
2
B
A
1
1
A
Sideways transfer
Folding back the armrest assembly
1. Fold (A) to the rear.
Caution!
Remove the tray before folding back the
armrest assembly.
4.3 Options / accessories
Removing/positioning the headrest
1. Loosen (A) by one turn.
2. Slide (B) out of or into the receiver.
3. Tighten (A).
Note!
Always slide the headrest until it comes to a
stop in the bracket.
Removing the side cushion
1. Loosen (A) by two turns
2. Slide (B) up
3. When replacing the side cushion, tighten (A)
by two turns
