10
Item
Designation
Function
2
Control lever
Control the steering and brake of the truck.
7
Fault indicator
Normally on normal condition. Failure regularity, see
the failure code.
9
Charging light indicator
Green light: Fully charged.
Yellow lingth: Fault
Red light: Charging
13
Battery charging plug（ built-in
plug）
Insert the plug into the power outlet for battery
charging.
14
Instrument
Shows the accumulated operating hours of the truck,
the residual capacity of the battery and the fault
code(refer to “Instrument” part)
16
Emergency stop switch
Cut the connection with the battery, close all electric
function and brake.
17
Key switch
Switches the control current ON and OFF.
The truck cannot be operated by unauthorized
persons when the key has been removed from the
switch.
18
Upright traveling button
Press the button, the control lever in vertical state
truck can run.
19
“Lower” button
Lower lifting device.
20
“Lift” button
Raise lifting device. When the battery is consumed
about 80%, lifting function will be locked.
21
Horn button
Give out sound warning signal.
22
Travel switch
Control travelling direction and speed.
23
Collision safety switch
Truck moves away from operator.
Protect the operator from extrusion damage under
emergent circumstances.
