1.5 Electromagnetic brake
The spring-loaded electromagnetic brake is applied in the truck which is a single disk brake with
double friction surfaces. By use of the pressure spring, powerful braking torque would be
generated when power off. The brake could be released by the electromagnetic effect.
1.Mounting Bolt of the Brake
3.Brake Pad
5.Friction Disk
2.Stator Module
4.Shaft Sleeve
6.Dustproof Cover
Fig. 2-3 Electromagnetic brake parts
