HANGCHA CBD15-A2MC1 - Part Ⅱ：structure, Principle and Maintenance; Drive Unit; Data Sheet

47
Part Ⅱ：Structure, Principle and Maintenance
1 Drive Unit
1.1 Data sheet
Speed ratio of reduction gear box
24.6857
Max. wheel torque
N•m
250
Max. wheel load
kg
1000
Drive motor
Rated voltage
V
24
Rated power
kW
0.65
Rated current
A
38
Rated speed
r/min
3100
Working system
S2=45min
Insulation grade
F
Protection grade
IP44
Using the environment temperature
℃
-10～+40
The service life of the brush
h
＞1200
Brake
Rated voltage
V
24
Rated power
W
20
Rated braking torque
N•m
4
Rated Air Gap
mm
0.15～0.30
Pre-tension torque of the mounting screw
Nm
2.8
