5.3 Battery charging
That is, during truck operation the battery discharge process, the battery over-discharge is
prohibited. After the truck is running, it is timely to charge the battery.
WARNING
 The truck comes with charger, the charger charging power supply must be
single-phase power frequency AC power. It’s prohibited to use DC, AC two
phase/three phase and other non single phase AC to charge the battery.
5.3.1 Power interface
– Input voltage: 85VAC～265VAC
– Input frequency: 47Hz～63Hz
– Input current: 1.8A～3.5A
5.3.2 Battery charging steps
Procedure:
– Park the truck securely.
– Remove the charging plug (13), together with the wire fixator (12) from the hood (15).
– The battery charging plug (13) is inserted into the appropriate electrical outlet.
– To charge the battery until the charging light indicator(9) green on, the battery is full charged.
LED red on—Charging mode
LED green on—Full charged
LED yellow flash—Charger fault
LED yellow on—Battery fault
– Remove charging plug (13) with the wire fixator (12) from the power socket and plug into the
hood (15).
CAUTION
 When the battery capacity is less than 3 grid please charge, otherwise will damage
the battery, not the warranty !
 Truck travelling function is prohibited when charging.
 Do not suspend charging before fully charged.
