HANGCHA CBD15-A2MC1 - Remove or Installing the Drive Wheel Cover

42
9.4 Remove or installing the drive wheel cover
Remove the drive wheel cover
Procedure:
– Unscrew the drive wheel cover(4) of the four screws(37), remove the drive wheel cover.
The drive wheel cover is removed. Installation and removal process is reversed.
WARNING
 Remove or installing the drive wheel cover, carefully clip hand !
4
37
37
