PARTS LIST
MAINTENANCE KITS
MODEL 4 6 7.5 10
Includes Elements, Drain Rebuild Kit,
Bowl O-Rings, and Water Valve Strainer
Screen
HPETMK10 HPETMK10 HPETMK11 HPETMK12
PARTS DESCRIPTION 4 6 7.5 10
Compressor 4006286 3210944 3210945 3221271
Fan Motor 3233147 4010923 4010925 4010925
Fan Blade 3219400 3094035 3210272 3210272
Crankcase Heater 4010508 4010508 3223269 3223269
Low Refrigerant Pressure Switch 3230768 3230768 3230768 3230768
High Refrigerant Pressure Switch (AC) 3230770 3230770 3230770 3230770
High Refrigerant Pressure Switch (WC) 3230771 3230771 3230771 3230771
Fan Cutout Switch 1 3230765 3230765 3230765 3230765
Fan Cutout Switch 2 3230766 3230766 3230766 3230766
Hot Gas By-Pass Valve 3232527 3232527 3232548 3232548
Thermal Expansion Valve 3232550 3232550 3232550 3232532
De-Superheating Valve 3232542 3232542 3232542 3232531
Liquid Line Filter Dryer 4006402 4006402 4006402 4006402
Suction Filter — — 4006414 4006414
Cooling Water Regulating Valve 4006391 4006391 4006391 4006392
Cooling Water Strainer 4009635 4009635 4009635 4009636
Cooling Water Strainer Screen 3230673 3230673 3230673 3230662
Temperature Sensor 3210926 3210926 3210926 3210926
Contactor 5002928 5002928 5002928 5002928
Auxiliary Contactor 5002929 5002929 5002929 5002929
Control Transformer 3159128 3159128 3159128 3159128
Fuse Primary 3223953 3223953 3223953 3223953
Fuse Secondary 4010495 4010495 4010495 4010495
Solid State Motor Protector — — 5004378 5004378
Electric Drain Valve 4009870 4009870 4009870 4009870
Display Board 3227172 3227172 3227172 3227172
Display Board Fuse 5002932 5002932 5002932 5002932
On-Off Switch 3230777 3230777 3230777 3230777
(AC) - Air Cooled Model
(WC) - Water Cooled Model
