15
DIMENSIONS
inches [
mm
]
MODEL 500-600-700 800-1000 1200 1600 2000/2300
A 65-1/4 75-3/4 70-3/4 85 85
[
1657
][
1924
][
1797
][
2159
][
2159
]
B3838484848
[
965
][
965
][
1219
][
1219
][
1219
]
C4444505050
[
1118
][
1118
][
1270
][
1270
][
1270
]
D 68-1/2 79 74-1/4 87-3/4 87-3/4
[
1740
][
2007
][
1886
][
2229
][
2229
]
E 12-1/2 12-1/2 13-1/4 13-1/4 13-1/4
[
318
][
318
][
337
][
337
][
337
]
F 5-1/4 5-1/4 5-1/4 6-1/4 6-1/4
[
133
][
133
][
133
][
159
][
159
]
G 3" NPT or 3" NPT or 4" ANSI or 6" ANSI or 6" ANSI or
DN80 Flange DN80 Flange DN100 Flange DN150 Flange DN150 Flange
H 12-3/4 12-3/4 17-3/8 17-3/8 17-3/8
[
324
][
324
][
441
][
441
][
441
]
J 35-3/8 35-3/8 44-3/4 45-3/8 45-3/8
[
899
][
899
][
1137
][
1150
][
1150
]
K 41-3/8 41-3/8 45-3/4 47-3/8 47-3/8
[
1051
][
1051
][
1162
][
1203
][
1203
]
L 5/8 5/8 5/8 5/8 5/8
[
16
][
16
][
16
][
16
][
16
]
M2 222 2
[
51
][
51
][
51
][
51
][
51
]
N 10-3/4 10-3/4 9-1/2 10-1/4 10-1/4
[
273
][
273
][
241
][
260
][
260
]
P 16-3/4 16-3/4 15-1/2 16-3/4 16-3/4
[
426
][
426
][
394
][
425
][
425
]
Q2 222 2
[
51
][
51
][
51
][
51
][
51
]
R 7 7 5-3/4 5-3/4 5-3/4
[
178
][
178
][
146
][
146
][
146
]
S 9 9 7-3/4 7-3/4 7-3/4
[
229
][
229
][
197
][
197
][
197
]
T 1/2" 3/4" 3/4" 3/4" 3/4"
U 13-1/2 19 12-1/4 12-1/4 12-1/4
[
343
][
483
][
311
][
311
][
311
]
WEIGHTS
912 lbs [
414 kg
] 1288 lbs [
584 kg
] 1486 lbs 2173 lbs 2396 lbs. [
1087 kg
]
A/C 1024lbs [
465 kg
] 1365 lbs [
619 kg
][
675 kg
][
986 kg
] 2715 lbs [
1232 kg
]
1066 lbs [
484 kg
]
892 lbs [
404 kg
] 1230 lbs [
558 kg
] 1466 lbs 2153 lbs 2376 lbs [
1078 kg
]
W/C 1004 lbs [
455 kg
] 1305 lbs [
592 kg
][
666 kg
][
977 kg
]
1046 lbs [
474 kg
]
DIMENSIONS AND WEIGHTS
LEFT SIDE VIEW FRONT VIEW
TOP VIEW
NOTE: Dimensions and Weights are for reference only. Request certified
drawings for construction purposes.
M
3 mm
(1/8")
EH
F
Q
WATER
CONNECTIONS
B
C
AIR COOLED MODELS ONLY
914mm (36")
Minimum clearance for
free air flow both sides
All models 914mm (36")
minimum clearance should be
provided on
front and left side for maintenance
M
MANUAL DRAIN VALVE
1/4" NPT (F)
AUTOMATIC DRAIN
1/4" NPT (F)
G AIR CONNECTION
Flange standard on models 1200 and larger
K
MOUNTING CENTERS MOUNTING CENTERS
SCREEN
M
L
DIA. MTG. HOLES
(4 REQ'D)
29mm Dia.
(1-1/8")
ELECTRICAL
CONN. ENTRY
U
SEE DETAIL "A"
DETAIL "A"
Drain Location
M
M
T WATER INLET
T WATER OUTLET
N
P
AIR INLETAIR OUTLET
A
D
J
R
S
FAN AIR FLOW
FAN AIR FLOW
