Modbus Register Details
Page 1 of 3
Dryer Status
Register 40001
Decimal Hex
Description
0 0x0000 Standby
1 0x0001 Fixed
2 0x0002 PID
3 0x0003 Reserved
4 0x0004 Reserved
5 0x0005 Reserved
6 0x0006 Reserved
7 0x0007 Reserved
Dryer Alarm Flags
Register 40002
Bit Mask
Description
0 0x0001 High Discharge Temperature
1 0x0002 High Refrigerant Pressure
2 0x0004 Low Refrigerant Pressure
3 0x0008 Compressor #1
4 0x0010 Compressor #2
5 0x0020 Oil Protection #1
6 0x0040 Oil Protection #2
7 0x0080 Phase Reversal
8 0x0100 Phase Loss
9 0x0200 Evaporator Temperature Sensor Failure
10 0x0400 Glycol Temperature Sensor Failure
11 0x0800 Evaporator Outlet Temperature Sensor Failure
12 0x1000 Discharge Temperature Sensor failure
13 0x2000 High Super Heat
14 0x4000 Reserved
15 0x8000 Reserved
Dryer Warning Flags
Register 40003
Bit Mask
Description
0 0x0001 High Evaporator Temperature
1 0x0002 High Glycol Temperature
2 0x0004 Heater #1
3 0x0008 Heater #2
4 0x0010 Drain #1
5 0x0020 Drain #2
6 0x0040 Filter #1
7 0x0080 Filter #2
8 0x0100 Reserved
9 0x0200 Reserved
10 0x0400 Reserved
11 0x0800 Reserved
12 0x1000 Reserved
13 0x2000 Reserved
14 0x4000 Reserved
15 0x8000 Reserved
