HANKISON SPX FLOW HES Series User Manual

25
6.0 DIMENSIONS / WEIGHTS
Dimensions in (mm)
Model
Height
(A)
Width
(B)
Depth
(C) (D) (E) (F)
Weight
Lb. (kg)
Inlet/Outlet
Connections
800
1000
1250
1500
85.1/8 (2162)
85.1/8 (2162)
85.1/8 (2162)
85.1/8 (2162)
48.1/2 (1232)
48.1/2 (1232)
48.1/2 (1232)
48.1/2 (1232)
40.3/4 (1035)
40.3/4 (1035)
50.3/4 (1289)
50.3/4 (1289)
12.1/2 (318)
12.1/2 (318)
13.1/4 (337)
13.1/4 (337)
12.7/8 (327)
12.7/8 (327)
11.1/4 (286)
11.1/4 (286)
8.3/4 (222)
8.3/4 (222)
8.1/2 (216)
8.1/2 (216)
1124 (510)
1146 (520)
1521 (690)
1563 (709)
3” ANSI Flg.
3” ANSI Flg.
4” ANSI Flg.
4” ANSI Flg.
1750
2000
2500
3000
85.1/8 (2162)
85.1/8 (2162)
85.1/8 (2162)
85.1/8 (2162)
55.1/8 (1400)
55.1/8 (1400)
55.1/8 (1400)
55.1/8 (1400)
59.3/8 (1508)
59.3/8 (1508)
59.3/8 (1508)
59.3/8 (1508)
13.1/4 (337)
13.1/4 (337)
13.1/4 (337)
13.1/4 (337)
31.1/4 (794)
31.1/4 (794)
31.1/4 (794)
31.1/4 (794)
9.1/8 (232)
9.1/8 (232)
9.1/8 (232)
9.1/8 (232)
1940 (880)
1997 (906)
2315 (1050)
2646 (1200)
6” ANSI Flg.
6” ANSI Flg.
6” ANSI Flg.
6” ANSI Flg.
NOTE: Dimensions and weights are for reference only. Request certified drawings for construction purposes.
1750 - 3000 scfm
800 - 1000 scfm
1250 - 1500 scfm
C
B
E
OUTLET
FD
INLET
A
LEFT SIDE VIEW
FRONT VIEW
RIGHT SIDE VIEW
TOP VIEW
C
B
ED
F
INLET
OUTLET
A
LEFT SIDE VIEWFRONT VIEW
RIGHT SIDE VIEW
TOP VIEW
B
C
E
INLET
D
F
OUTLET
A
LEFT SIDE VIEW
FRONT VIEW
RIGHT SIDE VIEW
TOP VIEW
