HANKISON SPX FLOW HES Series User Manual

39
REPLACEMENT PARTS
ID# PARTS DESCRIPTION 800 1000 1250 1500 1750 2000 2500 3000
1
Refrigerant Type (see Serial Tag for charge amount)
R-404a R-404a R-404a R-404a R-404a R-404a R-404a R-404a
2
Compressor - Digital Scroll
7425996 7425997 7425997 3221280 3221280 3221281 3221281 3221281
3
Compressor - Fixed Scroll
N/A N/A N/A 3221282 3221282 3221282 3210948 3210948
4
Condenser Assembly (includes condenser and fans)
8000285 8000285 8000286 8000293 8000294 8000294 8000295 8000296
5
Contactor - Compressor - Digital Scroll
1
7419137 7419137 7419137 7419137 7419137 7419137 7419137 7419137
6
Contactor - Compressor - Fixed Scroll
1
N/A N/A N/A 7419137 7419137 7419137 7419137 7419137
7
Contactor - Fan Motor
1
7419137 7419137 7419137 7419137 7419137 7419137 7419137 7419137
8
Auxiliary Contacts - Compressor
1
7427939 7427939 7427939 7427939 7427939 7427939 7427939 7427939
10
Control Board - Digital Scroll Control
1, 2
7426184 7426184 7426184 7426184 7426184 7426184 7426184 7426184
11
Disconnect Switch
3246083 3246083 3246083 3246083 3246083 3246083 3246083 3246083
12
Fan Assembly (includes motor, blade and guard)
3243804 3243804 3243804 3243805 3243805 3243805 3243805 3243805
13
Filter/Dryer - Liquid Line
3223812 3223812 3223812 3223812 3243615 3243615 3243616 3243616
14
Fuse - Control Board
1
5002943 5002943 5002943 5002943 5002943 5002943 5002943 5002943
15
Fuse - Control Transformer - Primary
1
3246089 3246089 3246089 3246089 3246089 3246089 3246089 3246089
16
Fuse - Control Transformer - Secondary
1
3246090 3246090 3246090 3246090 3246090 3246090 3246090 3246090
17
Fuse - Crankcase Heater
1
3246089 3246089 3246089 3246089 3246089 3246089 3246089 3246089
18
Heater, Crankcase
4010508 4010508 4010508 4010508 4010508 4010508 4010508 4010508
19
Motor Starter Protector - Compressor - Digital
1
5003506 5003506 5003506 5003506 5003506 5003506 5003506 5003506
20
Motor Starter Protector - Compressor - Fixed
1
5003506 5003506 5003506 5003506 5003506 5003506 5003506 5003506
21
Motor Starter Protector - Fan
1
3246077 3246077 3246077 3246078 3246078 3246078 3246078 3246079
22
Relay - High Pressure Cut-out
1
3246088 3246088 3246088 3246088 3246088 3246088 3246088 3246088
23
Sensor - Temperature
1
5007289 5007289 5007289 5007289 5007289 5007289 5007289 5007289
26
Switch - Fan Cut-out #1
3230765 3230765 3230765 3230765 3230765 3230765 3230765 3230765
27
Switch - Fan Cut-out #2
N/A N/A N/A 3230766 3230766 3230766 3230766 3230766
28
Switch - High Pressure Cut-out
3230770 3230770 3230770 3230770 3230770 3230770 3230770 3230770
29
Switch - Low Pressure Cut-out
3230769 3230769 3230769 3230769 3230769 3230769 3230769 3230769
31
Transformer - Control
1
3246082 3246082 3246082 3246082 3246082 3246082 3246082 3246082
32
Valve - Automatic Drain (complete)
7428268 7428268 7428268 7428268 7428268 7428268 7428268 7428268
33
Valve - Solenoid - Digital Scroll
3232517 3232517 3232517 3232517 3232517 3232517 3232517 3232517
34
Valve - Solenoid Assembly - Digital Scroll
(includes solenoid valve and sound attenuation volumes)
3219039 3219039 3219039 3219039 3219039 3219039 3219039 3219039
35
Valve - Thermostatic Expansion (TXV)
3232550 3232550 3232550 3232550 3232532 3232532 3232533 3232533
230/3/60 Units Only
36
Main Transformer - 230/460
1
3230908 3230906 3230906 3230906 3230906 3230896 3230896 3230896
575/3/60 Units Only
37
Main Transformer - 575/460
1
3230907 3230907 3230907 3230895 3230895 3230908 3230908 3230908
1
Items 5, 6, 7, 8, 9, 10, 14, 15, 16, 17, 19, 20, 21, 22, 23, 31, 36, and 37 are located in the electrical enclosure located behind the control panel. Refer to the appropriate Electrical Schematic to identify part.
2
NOTE: Consult factory with the dryer serial number when ordering Item 10, Control Board.
REPLACEMENT PARTS: AIR-COOLED UNITS
MAINTENANCE KITS
MODEL 800 1000 1250 1500 1750 2000 2500 3000
Moisture Separator Filter
(includes separator elements & drain rebuild kit)
HESMK27D2 HESMK27D2 HESMK27D2 HESMK27D2 HESMK28D2 HESMK28D2 HESMK28D2 HESMK28D2
Optional Oil Removal Filter
(includes separator elements, oil removal elements & drain rebuild kit)
HESMK47D2 HESMK47D2 HESMK47D2 HESMK47D2 HESMK48D2 HESMK48D2 HESMK48D2 HESMK48D2
Rebuild Kit - Automatic Drain
7428278 7428278 7428278 7428278 7428278 7428278 7428278 7428278
