HANKISON SPX FLOW HES Series - Controller Interface Screens - Status; Status Menu Screen Flow

22
Controller Screen Shots
Status Menu Screens
DEMM32 - User Interface Diagram
Page 1 of 4 Rev H. - 10/22/2014
Power-up Delay
Up/Down
Up/Down
Up/Down
Status Menu
Total Hours
30
HRS TO SERVICE
4970
xx/xx/xxxx xx:xx
MANUAL MODE
Version x.x
DISCHARGE
xxx.x°C / xxx°F
EVAPORATOR IN
xxx.x°C / xxx°F
Up/Down
EVAPORATOR OUT
xxx.x°C / xxx°F
Up/Down
DRYER LOAD
0%
ENERGY SAVINGS
$ 2108 / YEAR
Up/Down
Up/Down
Hidden if evaporator
outlet temperature
sensor = disabled
Hidden if energy
cost = 0.00
ALARM MESSAGE 1
ALARM MESSAGE 2
Shown for each
active alarm
Up/Down
Up/Down
