19
Model
800 1000 1250 1500 1750 2000 2500 3000
Electrical Data
Nominal Voltage 230/3/60 **
Voltage Range 207 - 253
Input Power @ Rated Flow (watts) * 4,710 6,730 7,400 9,770 13,010 14,870 16,840 18,200
Minimum Circuit Ampacity 21 26 26 41 41 46 52 59
Maximum Overcurrent Protector (amps) 30 40 40 60 60 75 80 90
Compressor Rated Load Amps *** 6.7 9.0 9.0 6.7 / 6.7 6.7 / 6.7 9.0 / 6.7 9.0 / 9.1 9.0 / 9.1
Compressor Locked Rotor Amps *** 48 70 70 48 / 48 48 / 48 70 / 48 70 / 70 70 / 70
Compressor Winding Resistance (ohms) *** 3.64 2.27 2.27 3.64 / 3.64 3.64 / 3.64 2.27 / 3.64 2.27 / 2.27 2.27 / 2.27
Nominal Voltage 460/3/60
Voltage Range 414 - 506
Input Power @ Rated Flow (watts) * 4,710 6,730 7,400 9,770 13,010 14,870 16,840 18,200
Minimum Circuit Ampacity 10 13 13 20 20 23 26 30
Maximum Overcurrent Protector (amps) 15 20 20 30 30 35 40 45
Compressor Rated Load Amps *** 6.7 9.0 9.0 6.7 / 6.7 6.7 / 6.7 9.0 / 6.7 9.0 / 9.1 9.0 / 9.1
Compressor Locked Rotor Amps *** 48 70 70 48 / 48 48 / 48 70 / 48 70 / 70 70 / 70
Compressor Winding Resistance (ohms) *** 3.64 2.27 2.27 3.64 / 3.64 3.64 / 3.64 2.27 / 3.64 2.27 / 2.27 2.27 / 2.27
Nominal Voltage 575/3/60 **
Voltage Range 518 - 633
Input Power @ Rated Flow (watts) * 4,710 6,730 7,400 9,770 13,010 14,870 16,840 18,200
Minimum Circuit Ampacity 8 11 11 16 16 19 21 24
Maximum Overcurrent Protector (amps) 12 17.5 17.5 25 25 30 35 35
Compressor Rated Load Amps *** 6.7 9.0 9.0 6.7 / 6.7 6.7 / 6.7 9.0 / 6.7 9.0 / 9.1 9.0 / 9.1
Compressor Locked Rotor Amps *** 48 70 70 48 / 48 48 / 48 70 / 48 70 / 70 70 / 70
Compressor Winding Resistance (ohms) *** 3.64 2.27 2.27 3.64 / 3.64 3.64 / 3.64 2.27 / 3.64 2.27 / 2.27 2.27 / 2.27
Nominal Voltage 380-420/3/50
Voltage Range 342 - 462
Input Power @ Rated Flow (watts) * 3,010 4,330 4,730 6,250 8,320 9,510 10,780 11,650
Minimum Circuit Ampacity 10 13 13 20 20 23 26 30
Maximum Overcurrent Protector (amps) 15 20 20 30 30 35 40 45
Compressor Rated Load Amps *** 6.7 9.0 9.0 6.7 / 6.7 6.7 / 6.7 9.0 / 6.7 9.0 / 9.1 9.0 / 9.1
Compressor Locked Rotor Amps *** 48 70 70 48 / 48 48 / 48 70 / 48 70 / 70 70 / 70
Compressor Winding Resistance (ohms) *** 3.64 2.27 2.27 3.64 / 3.64 3.64 / 3.64 2.27 / 3.64 2.27 / 2.27 2.27 / 2.27
Notes
* 60 Hz: 35°F Evaporator & 100°F Ambient; 50 Hz: 35°F Evaporator & 77°F Ambient
** 230/3/60 and 575/3/60 units use equipment transformers on incoming power. Compressor and fan voltage is 460/3/60.
*** Where two values are shown, the first is for the digital scroll compressor and the second is for the standard scroll compressor.
Engineering Data Table
Sheet 2 of 2
