Hankscraft Runxin RevV4 User Manual

RevV4 Valves & Systems Service Manual
10
Hankscraft Runxin, LLC 300 Wengel Drive 608.524.9465 hrh2o.com sales@hrh2o.com
• Do not use the system with water that is microbiologically unsafe or of unknown quality without
adequate disinfection before or after the system.
• Do not use the brine tube, injector body, or other connectors on the RevV4 valve as a handle to carry
the system.
• Ensure there is salt in the brine tank at all times when this valve is used for softening. The brine tank
should contain clean water softening salt only, at least 99.5% pure. Do not use small grain salt.
• When there is moderate to high turbidity, a filter should be installed before the water softening system
on the inlet side.
• If the water pressure exceeds 120psi, a pressure reducing valve must be installed before the water inlet. If
the water pressure exceeds 80 psi, installing a pressure reducing valve before the water inlet is highly
recommended. If the water pressure is under 20 psi, a booster pump must be installed before the
water inlet.
• Replacement parts for the RevV4 valve should only be purchased through Hankscraft Runxin resellers.
Electrical components, such as transformers, are specific to the RevV4 valve from Hankscraft.
• Regular interval monitoring of the water quality and work environment is recommended to ensure
proper operation of the valve and system.
• Any modification to Hankscraft equipment, which is outside the standard scope of supply, voids the
product warranty.
• Hankscraft equipment, like all modern electronic devices, can be damaged by electrical surges or brown
outs. Every effort has been taken to harden the circuits, by design, to protect against such events. These
precautions, or even additional surge protection, are not 100% effective. Therefore, equipment damage
caused by abnormal electrical events is not covered by warranty.

Hankscraft Runxin RevV4 Specifications

General

Brand	Hankscraft Runxin
Model	RevV4
Category	Control Unit
Language	English

Summary

2. Product Features and Applications

3. Product Dimensions and Specifications

4. Pre-Installation Checklist

5. Valve Installation

Unit Location

Plumbing and Mechanical Setup

Control Valve Installation

Step-by-step guide for installing the control valve onto the mineral tank.

6. Bypasses

7. Programming: Display and Instructions

Basic Programming

Adjust time values for each phase of operation.

Advanced Programming

Mode A-01: Meter Delay

Configures regeneration based on capacity and time delay.

Mode A-02: Meter Immediate

Configures immediate regeneration upon reaching zero capacity.

Mode A-03: Intelligent Meter Delay

Intelligent delay mode using capacity, hardness, and people count.

Mode A-04: Intelligent Meter Immediate

Intelligent immediate mode using capacity and hardness.

Mode A-05: Remaining Compare

Compares usage to historical data for regeneration timing.

Mode A-06: By Day (Timer)

Regeneration based on programmed service days and time.

Mode A-07: Filter Meter

Filter mode regeneration based on capacity and time.

8. PCB Functions and Connections

Signal Output

Signal Output Connector

Liquid Level Controller with Inlet Pump

Inlet Booster Pump

Interlock and Alternating Interlock

Remote Handling Connector

Interlock Options

9. System Installation

Valve Set-up and Installation

Plumbing Connections

Drain Line Installation

System Start-Up

Steps to follow for initial system start-up and verification.

Sanitation Procedure

10. Assembly Drawings and Parts List

11. Troubleshooting

Control Valve Troubleshooting

Lists common problems and their solutions for the control valve.

Electronics Troubleshooting

Addresses issues related to the control valve's electronic components and display.

12. Replacement Parts

15. Hankscraft Runxin, LLC Warranty Statement

16. System Configuration and Settings

Softener System Configuration

Valve Programming

17. Factory Default Settings
