Hankscraft Runxin RevV4 User Manual

RevV4 Valves & Systems Service Manual
5
Hankscraft Runxin, LLC 300 Wengel Drive 608.524.9465 hrh2o.com sales@hrh2o.com
2. Product Features and Applications
Primary Applications
Recommended for commercial and residential softening or demineralization water treatment systems .
• Softening System
• Iron Removal System
• Ion Exchange Equipment
• Boiler Softening Water Treatment
• RO Pre-treatment
Product Characteristics
Mechanical Components
The RevV4 uses internal ceramic discs which are corrosion and abrasion resistant to form a hermetic seal. Rotation of the
upper disc aligns to the corresponding lower disc ports for Service, Backwash, Brine & Slow Rinse, Brine Refill and Fast
Rinse modes.
Hard Water/No Hard Water Bypass
Up-flow regeneration with no hard water and hard water bypass options. This valve operates as a hard water bypass.
Excellent Flow Rate: 20 gpm @ 15 psi drop.
365-Day Usage Memory
Manual / Delayed Regeneration
Pressing at any time results in an immediate manual regeneration.
Pressing and holding for 3 seconds, when system is locked, results in a delayed regeneration at the preselected time.
Extended Power Outage Indicator
If outage exceeds 3 days, the time of day indicator “  ” will flash 12:12. The current time of day needs to be re-set. All
other set parameters remain stored in memory. The valve will resume to operate from the point of the power outage.
Three Regeneration Sequences
Lockout Function
Keypad will lock after 5 minutes without use. To access the parameter changes press and hold and
simultaneously for 3 seconds to unlock.

Hankscraft Runxin RevV4 Specifications

General

Brand	Hankscraft Runxin
Model	RevV4
Category	Control Unit
Language	English

Summary

2. Product Features and Applications

3. Product Dimensions and Specifications

4. Pre-Installation Checklist

5. Valve Installation

Unit Location

Plumbing and Mechanical Setup

Control Valve Installation

Step-by-step guide for installing the control valve onto the mineral tank.

6. Bypasses

7. Programming: Display and Instructions

Basic Programming

Adjust time values for each phase of operation.

Advanced Programming

Mode A-01: Meter Delay

Configures regeneration based on capacity and time delay.

Mode A-02: Meter Immediate

Configures immediate regeneration upon reaching zero capacity.

Mode A-03: Intelligent Meter Delay

Intelligent delay mode using capacity, hardness, and people count.

Mode A-04: Intelligent Meter Immediate

Intelligent immediate mode using capacity and hardness.

Mode A-05: Remaining Compare

Compares usage to historical data for regeneration timing.

Mode A-06: By Day (Timer)

Regeneration based on programmed service days and time.

Mode A-07: Filter Meter

Filter mode regeneration based on capacity and time.

8. PCB Functions and Connections

Signal Output

Signal Output Connector

Liquid Level Controller with Inlet Pump

Inlet Booster Pump

Interlock and Alternating Interlock

Remote Handling Connector

Interlock Options

9. System Installation

Valve Set-up and Installation

Plumbing Connections

Drain Line Installation

System Start-Up

Steps to follow for initial system start-up and verification.

Sanitation Procedure

10. Assembly Drawings and Parts List

11. Troubleshooting

Control Valve Troubleshooting

Lists common problems and their solutions for the control valve.

Electronics Troubleshooting

Addresses issues related to the control valve's electronic components and display.

12. Replacement Parts

15. Hankscraft Runxin, LLC Warranty Statement

16. System Configuration and Settings

Softener System Configuration

Valve Programming

17. Factory Default Settings
