RevV4 Valves & Systems Service Manual
46
Hankscraft Runxin, LLC 300 Wengel Drive 608.524.9465 hrh2o.com sales@hrh2o.com
Item
No.
Description Part No. Qty.
Item
No.
Description Part No. Qty.
1 O-ring, 32.5X3.55 8378116 1 37 Screw, Cross ST3.9X13 8909013 2
2 O-ring, 73x5.3 8378143 2 38 Screw, Cross M4×12 8902005 1
3 Screw, Cross ST2.9X16 8909010 1 39 Small Gear 8241019 1
4 Valve Body 8022742 1 40 Pin 8993003 1
5 Motor 6158052 1 41 Motor 6159511 1
6 Dust Cover 8005034 1 42 Fitting Nut 8092034 1
7 Control Board 6382025 1 43 O-ring, 17.5x2 8378182 1
8 Screw, Cross M2X10 8902035 1 44 O-ring, 6.08x1.78 8378155 4
9 Spring Washer 2 8953007 1 45 Seal Ring 30OD X 24ID X 3.3 8371001 1
10 Pick 8152017 2 46 Anti-friction Washer 8216013 2
11 Washer 8952008 2 47 Valve Rod 8206012 1
12 Spring Washer 8953008 1 48 Moving Disk 8459034 1
13 Screw, Cross M3X6 8902034 3 49 Screw, Cross ST2.2X6.5 8909004 1
14 Screw, Cross ST2.9X13 8909009 1 50 Fixed Disk 8469050 1
15 Seal Ring 8370075 1 51 Seal Ring 8370054 1
16
Fixed Disk 8469048
2 52
Brine Line Flow Control 8468052-8468057
4
17 Moving Disk 8459050 1 53 Filter Screen 8336008 4
18 O-ring, 90x3.55 8378180 4 54 Tube 8457039 1
19 O-ring, 43.7x3.55 8378123 1 55 O-ring, 11x2 8378169 2
20 Fitting Nut 8092033 1 56 Connector 8458068 1
21 Moving Seal Ring 8370065 1 57 Hexagonal Nut 8940001 2
22 Shaft 8258014 4 58 Articulated Nut 8945025 1
23 Anti-friction Washer 8216012 1 59 Connector 8458064 1
24 Locating Board 6378007 1 60 O-ring, 15x1.8 8378179 1
25 Screw, Cross ST2.9X9.5 8909008 1 61 Drain Line Flow Control 8468042-4468045 1
26 Gear 8241017 1 62 Clip 8270004 1
27 Dust Cover 8005033 1 63 Tube 8467001-8467010 1
28 Control Board 6382022 1 64 Injector Nozzle 8454001-8454010 1
29
Wiring of Locating Board 5511014
2 65
O-ring, 17x1.8 8378148
1
30 Wire for power 8513001 1 66 Injector Cover 8315003 1
31 Display Board 6381006 1 67 Screw, Cross M5X35 8902017 1
32 Front Cover 8300030 1 68 Screw, Cross M5X23 8902015 1
33 Label 8865040 1 69 Filter Screen 5336008 1
34 Wire for Display Board 5512002 1 70 O-ring, 7x1.8 8378015 1
35 Cable Clip 8126004 1 71 Injector Body 8008008 1
36 Dust Cover 8300031 1 72 O-ring, 7.5x1.8 8378016 1
To Next Page
