RevV4 Valves & Systems Service Manual
50
Hankscraft Runxin, LLC 300 Wengel Drive 608.524.9465 hrh2o.com sales@hrh2o.com
12. Replacement Parts
Description Part Number Quantity
Brine Assembly Kit, 3/8" - #63, #64, #65, #66, #68, #73 REVV-217
Brine Screen and Tube - #63, #65 REVV-218 1
Bypass Clip 8270004 1
Control Board Kit - #35, #37, #39 REVV-221 1 Kit
Display Board Kit - #33, #34, #37 REVV-222 1 Kit
DLFC Buttons, BLFC Buttons & Injector Kit REVV-215 1 Kit
Drain Assembly Kit - #67, #69, #71 REVV-216 1 Kit
Injector Body Assembly Kit - #1-3, #5, #7-11, #13, #56-69, #71, #73 REVV-220 1 Kit
Injector Cover O-ring - #3 8378148 1
Injector Filter Screen Kit - #5, #7 REVV-219 1 Kit
Locating Board Kit - #44, #45, #38 REVV-223 1 Kit
Meter Cable Assembly Kit - #36 & #37 REVV-232 1 Kit
Motor - #20 6158012 1
Motor, Brine - #17 6159052 1
O-ring, Valve Body - #12 8378143 1
O-ring, Valve Center Hub - #14 8378116 1
Transformer, 12VDC 6379021 1
Upper Distributor Basket, 32mm REVV-213 1
