Programming: Modes A-06
Parameter Unit Default Description
Review Company Info Displays current programmed company information.
Language *
English
Set Company Info * Set company information for display. Three lines available for input
Set Time of Day 24-hr. Clock
Set current time of day. 24-hour clock format.
Set Date Set current month, day, and year. XX/XX/20XX
Set Program Type *
Interlock / Alternate Interlock
Interlock
Used as a stand-alone installation and twin demand in conjunction with No
Hard Water version of the RevV4.
Set Regen Cycles * 1, 2, 3 2
Recommended setting to Sequence 2. See Pages 7-8. Service → Backwash
→ Brine & Slow Rinse → Back Wash → Fast Rinse → Brine Refill.
Set Clear Data * Close/Open Close
Skip during initial set-up. Clears all stored memory and restores default
settings. Close = Data saved Open = Reset data
Set Regen Mode: A-01-A-07 *
A-03 Change to A-06 Timer.
Set Service Days Days 3 Number of days between regenerations.
Set Regen Time 24-hr. Clock 02:00
The time of day the system will regenerate when it reaches system
capacity.
Set Backwash Time Min. 0 Set to 0 (zero) when using Sequence 2 as a softener install.
Set B.S.R. Time Min. 60 Brine Slow Rinse Stage of Regeneration.
Set Secondary B.W.T.
(Backwash Time)
Min. 10
Set Fast Rinse Time Min. 10
Set B.R. Time (Brine Refill) Min:Sec 10:00
Refill time is calculated based on total resin volume. Note: 1 gal. water
dissolves 3 lbs. of salt. See note below for refill time.
Signal Output Mode b-01 (02) * b-01 Used for external device. b-01. Disregard for standard installation.
Set Service Alarm * Days 730
Alarm rings to prompt a service call. Occurs at the number of days set at
8pm for 2 minutes. Display changes to prompt the homeowner to call their
dealer.
Review Regen Times Displays the number of times the valve has regenerated independently.
Review Software Ver. Shows current software version of RevV4 valve.
Above parameters are located in standard program settings menu. (*) Denotes parameters located in advanced program settings menu.
