Hankscraft Runxin RevV4 User Manual

RevV4 Valves & Systems Service Manual
8
Hankscraft Runxin, LLC 300 Wengel Drive 608.524.9465 hrh2o.com sales@hrh2o.com
Regeneration
Mode
A-01 Meter Delay: Regeneration happens when the capacity reaches zero and the preset time of
regeneration is reached.
A-02 Meter Immediate: Regeneration happens when the capacity reaches zero.
A-03 Intelligent Meter Delay: The same delay function as A-01 but the capacity is determined by entering
the total Resin Capacity, Feed Water Hardness, and the Number of People in the household. The control
valve automatically calculates the gallons for regeneration.
A-04 Intelligent Meter Immediate: The same function as A-02 but the capacity is determined by entering
the Total Resin Capacity and Feed Water Hardness. The control valve automatically calculates the gallons
for regeneration.
A-05 Remaining Compare: Compares current usage with previous 365 day daily usage to intelligently
determine when regeneration will occur. Regeneration starts at the set regeneration time.
A-06 By Day (timer): Service days count down to zero (0) and regeneration starts at the set regeneration
time.
A-07 Filter Meter: Filter mode, regeneration occurs when the capacity reaches zero and the preset time
for regeneration is reached.

Hankscraft Runxin RevV4 Specifications

General

Brand	Hankscraft Runxin
Model	RevV4
Category	Control Unit
Language	English

Summary

2. Product Features and Applications

3. Product Dimensions and Specifications

4. Pre-Installation Checklist

5. Valve Installation

Unit Location

Plumbing and Mechanical Setup

Control Valve Installation

Step-by-step guide for installing the control valve onto the mineral tank.

6. Bypasses

7. Programming: Display and Instructions

Basic Programming

Adjust time values for each phase of operation.

Advanced Programming

Mode A-01: Meter Delay

Configures regeneration based on capacity and time delay.

Mode A-02: Meter Immediate

Configures immediate regeneration upon reaching zero capacity.

Mode A-03: Intelligent Meter Delay

Intelligent delay mode using capacity, hardness, and people count.

Mode A-04: Intelligent Meter Immediate

Intelligent immediate mode using capacity and hardness.

Mode A-05: Remaining Compare

Compares usage to historical data for regeneration timing.

Mode A-06: By Day (Timer)

Regeneration based on programmed service days and time.

Mode A-07: Filter Meter

Filter mode regeneration based on capacity and time.

8. PCB Functions and Connections

Signal Output

Signal Output Connector

Liquid Level Controller with Inlet Pump

Inlet Booster Pump

Interlock and Alternating Interlock

Remote Handling Connector

Interlock Options

9. System Installation

Valve Set-up and Installation

Plumbing Connections

Drain Line Installation

System Start-Up

Steps to follow for initial system start-up and verification.

Sanitation Procedure

10. Assembly Drawings and Parts List

11. Troubleshooting

Control Valve Troubleshooting

Lists common problems and their solutions for the control valve.

Electronics Troubleshooting

Addresses issues related to the control valve's electronic components and display.

12. Replacement Parts

15. Hankscraft Runxin, LLC Warranty Statement

16. System Configuration and Settings

Softener System Configuration

Valve Programming

17. Factory Default Settings
