SPECIFICATIONS
Range - non ratio mode 0.00 to 9.99; 10.0 to 40.0 NTU
0.0 to 99.9; 100 to 268 Nephelos
0.00 to 9.80 EBC
Resolution - non ratio mode 0.01; 0.1 NTU
0.1; 1 Nephelos
0.01 EBC
Range - ratio mode 0.00 to 9.99; 10.0 to 99.9; 100 to 4000 NTU
0.0 to 99.9; 100 to 26800 Nephelos
0.00 to 9.99; 10.0 to 99.9; 100 to 980 EBC
Resolution - ratio mode 0.01; 0.1; 1 NTU
0.1; 1 Nephelos
0.01; 0.1, 1 EBC
Range selection Automatically
Accuracy ±2% of reading plus 0.02 NTU (0.15 Nephelos; 0.01 EBC)
±5% of reading above 1000 NTU (6700 Nephelos; 245 EBC)
Repeatibility ±1% of reading or 0.02 NTU (0.15 Nephelos; 0.01 EBC)
whichever is greater
Stray Light < 0.02 NTU (0.15 Nephelos; 0.01 EBC)
Light Detector Silicon Photocell
Method Nephelometric method (90°) or Ratio Nephelometric Method
(90° & 180°), Adaptation of the USEPA Method 108.1 and
Standard Method 2130 B.
Measuring mode Normal, Average, Continuous.
Turbidity Standards <0.1, 15, 100, 750 and 2000 NTU
Calibration Two, three, four or five-point calibration
Light Source Tungsten filament lamp
Lamp life greater than 100,000 readings
Display 40 x 70mm graphic LCD (64x128 pixels) with backlight
LOG Memory 200 records
Serial Interface USB
Environment 0°C (32°F) to 50°C (122°F); max 95% RH non-condensing
Power supply 230 V/50 Hz or
115 V/60 Hz 20 W
Auto Shut-off After 15 minutes of non-use
Dimensions 230 x 200 x 145 mm (9 x 7.9 x 5.7”) L x W x H
Weight 2.5 Kg (88 oz.)
