30
PC INTERFACEPC INTERFACE
PC INTERFACEPC INTERFACE
PC INTERFACE
Log data download from the instrument to the PC can be done with the HI 92000 Windows compatible
software (optional). HI 92000 also offers graphing and on-line help features. Data can be exported to the
most popular spreadsheet programs for further analysis.
To connect your instrument to a PC, use a standard USB cable. Make sure that your instrument is switched
off. Plug one connector to the instrument’s USB socket and the other to the USB port of your PC.
Please reffer to the HI 92000 software to download the data from the instrument.
To replace the lamp follow the next steps:
• Power off the instrument and take out the power cord.
• Remove the fixing screw of the lamp lid.
• Remove the lamp lid.
• Unscrew the lamp leads from connector.
• Unlock the lamp and extract it by pulling it out from
the lamp holder handler.
• Place the new lamp in the right position and push it
until is securely locked.
• Insert the lamp leads into the connector and tight them
using a screwdriver.
• Place back the lamp lid and secure with the screw.
Warning: After lamp replacement the meter has to be recalibrated.
LAMP REPLACEMENTLAMP REPLACEMENT
LAMP REPLACEMENTLAMP REPLACEMENT
LAMP REPLACEMENT
The instrument tungsten lamp has a life longer than 100,000 measurements. In case of lamp
failure, the defective lamp can be easily replaced. When the lamp is broken, the instrument displays
a lamp error message.
FUSE REPLACEMENTFUSE REPLACEMENT
FUSE REPLACEMENTFUSE REPLACEMENT
FUSE REPLACEMENT
To change the fuse follow next steps:
• Disconnect the power cord from the rear panel of the instrument.
• Pull out the fuse holder located near the power cord connector.
• Replace the fuse with a similar one.
• Push the fuse holder with the fuse in the appropriate place.
