System Menu Items 32
• A log (file) can store 1 to 50 000 records i.e. saved measurement data points.
• A single user can store a maximum of 1 000 000 data points.
• Removing or deleting logs frees up log space for additional log files.
View
Data can be viewed, plotted (graph), or tabulated (complete with date, time, notes).
From the System Menu screen:
1. Tap
(Log Recall). The instrument displays the Log Recall screen.
Tap on corresponding table header element to order logged data by Name, Parameter, Start / Stop time
stamp, #Samples.
Tap the up arrow to reverse order.
Note: Option available with .CSV file selected only.
2. Tap Name field to select .CSV file.
3. Tap View.
4. Tap
or icon to have logged data displayed in tabulated form or plotted.
