Connections
Measurement
1 x BNC Socket (pH, ORP, ISE half-cell and ISE combination electrodes)
1 x 4 mm Banana Socket (reference electrode)
1 x RCA Socket (temperature sensor)
1 x 6-pin Connector (stirrer)
Peripheral
1 x 6-pin Mini DIN (external PC keyboard)
1 x DB-25 Socket (printer)
1 x USB Standard B (PC connection)
1 x DB-9 Socket (analytical balance)
1 x USB Standard A (USB flash drive)
Additional
Specifications
Electrode Holder
4 x multi-purpose slots (titrant/reagent tubes)
3 x 12-mm electrode slots
1 x temperature sensor slot
1 x overhead stirrer slot
Display 5.7" graphical color display with backlight
Languages English, Portuguese, Spanish
Power Supply 100-240 Vac, 50/60 Hz
Power Draw 0.5 Amps
Enclosure Material ABS, PC and Stainless Steel
Keypad Polyester
Dimensions 315 x 205 x 375 mm (12.4 x 8.1 x 14.8 ")
Weight approx. 4.3 kg (9.5 lbs.) with 1 pump, stirrer and sensors
Operating
Environment
10 to 40 °C (50 to 104 °F); up to 95 % RH
Storage
Environment
-20 to 70 °C (-4 to 158 °F); up to 95 % RH
