The user interface contains several screens. For each titrator function, one or more screens are used.
3.2.3. THE MAIN SCREEN
After start up and initialization, the first screen displayed is the main screen.
Main screen fields:
Method name: Displays the name of the selected method.
Time and date: Displays the current date and time.
Temperature reading: Displays the measured temperature.
ATC: Automatic temperature compensation
Manual: Manual temperature compensation
Manual
: Temperature probe is not connected, manual temperature compensation
Stirrer information: The selected stirrer and actual/set stirrer speed is displayed in RPM. When stirrer is off,
the stirrer information is not displayed.
End point volume: Displays the volume delivered to reach the titration end point. When no titration
has been performed, the displayed volume is “0.000 mL”.
Result: Displays the titration result or the direct reading measurement.
mV or pH reading: Displays the current readings. The reading will be in mV or pH.
mV: Indicates actual potential reading.
rel mV: Indicates relative potential reading.
pH: Indicates actual pH value.
Titration status: Displays the status of the selected titration.
is displayed when a titration has not been performed.
Reminders: Indicates when a task needs to be performed and displays error
Pump 1 selected: Displays the active pump.
