Hanna Instruments HI931 - Menu Navigation

3-7
USER INTERFACE
3.3. MENU NAVIGATION
3.3.1. SELECTING AN OPTION
To select an option, simply press the option key below the virtual key. For example, to
access the Method Options screen press the option key below it.
3.3.2. SELECTING A MENU ITEM
To select an item from the menu screen, use the arrow keys and to move the
cursor.
When the menu is larger than the display, a scroll bar is active on the right side.
The and keys can be used to scroll through the pages.
To activate the selected menu item, press or .
3.3.3. ENTERING TEXT
To enter text in an alphanumeric input box, first erase the previous text by using .
To enter a letter, highlight it using the arrow keys then press . Use the same
procedure to enter the whole name.
For editing, use the and keys.
When editing is complete, press .
The method name will be updated and displayed in the name field of the View/Modify
Method screen.
When all the desired parameters have been set, press .
