3.2.1.3. ARROW KEYS
These keys have the following functions:
• Move the on-screen cursor.
• Increase and decrease the stirrer speed and other settings.
• In the alphanumeric screen, to select a character.
• Navigate through menu options.
3.2.1.4. NUMERIC KEYS
Keys to Used for numeric entries.
Toggles between positive and negative values.
Decimal point.
3.2.1.5. ENTER KEY
This key has the following functions:
• Accept alphanumeric data entry.
• Executes the default (underlined) virtual option key.
3.2.2. DISPLAY
The titrator has a large color graphical display. The main screen is shown below with short explanations of the screen segments.
