Bolt torque
Relative Strength Bolt Marking
4.6
8.8
Recommended Tightening Torque
Recommended Tightening Torque
Bolt size
Spanner size
lb ft
Nm
lb ft
Nm
M8
13 mm
6
8.5
16
22
M10
16 mm
12.5
17
32
44
M12
18 mm
22
30
57
77
M16
24 mm
54
73
140
190
M20
30 mm
105
143
274
372
Specifications
C13
General
Length
1100 mm
Width
1000 mm
Height
1400 mm
Weight
220 kg
Motor
Make & model
Honda GX340
Max Power
13 HP
Cutting System
Disc speed
2000 RPM
Disc dimensions
560 x 12 mm
Shaft diameter
31.75 mm
Knives
2
Feed System
Chipping capacity
90 mm
Feed type
Gravity fed, self-feeding
Inlet chute opening
170 x 220 mm
Discharge System
Discharge height
1120 mm
Outlet chute type
Fixed outlet with deflector
