Close the locking hinge and fasten the
two m6 bolts, spring washers, and
washers to the locking pin on each side
of the outlet using a 10 mm spanner.
Ensure the spring washer is between
the bolt head and washer.
Tighten the outlet chute locking handle
to secure the outlet chute to the
chipper body.
Note: The outlet chute locking handle
will be in the documentation package.
Fix the inlet chute - place the inlet
chute onto the chipper body with the
black rubber flap sandwiched in
between and ensure all three holes line
up. Tighten the nuts, washers, and
bolts using a 16 mm and 17 mm
spanner. Ensure that the washer is
touching the bolt head.
Line up holes and insert the bolts,
washers and nuts, ensuring the big
washer is touching the bolt head.
Safety
Preventing accidents is the responsibility of every equipment operator. The operator is responsible for any accidents or hazards
occurring to people or their property. Ensure every operator is familiar with the safe operation procedures and controls of the
machine, how to identify hazards, and the steps required to avoid injury while handling and operating the chipper. Relevant
information is contained in this manual.
Do NOT modify the design of the chipper.
Operator competency
Ensure that every person operating the chipper understands and follows the safe operating and maintenance procedures
as detailed in this manual.
Do NOT allow persons below the age of 18 to operate the chipper. Additionally, local regulations may restrict the age of
the operator.
Do NOT allow persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge to
operate the machine.
