Assembling the chipper
When you receive your Hansa brush chipper, the inlet and outlet chute may not be assembled on the chipper. All the fasteners
(bolts, nuts and washers) will be attached to their respective components.
Tools required for assembly (not supplied):
• 16 mm spanner - to fit the inlet and outlet chute
• 17 mm spanner - to fit the inlet and outlet chute
• Two 24mm spanners – to fit the fixed outlet chute
Parts supplied for assembly
All fasteners included to fix inlet chute and outlet chute
onto the chipper
Inlet chute
Fixed outlet chute (if you have purchased a fixed outlet
chute model)
Swivel outlet chute (if you have purchased a swivel
outlet chute model)
Chipper body
