Greasing bearings & pivot points
Points that need to be greased are as follows (as per the diagram below):
1. Two bearings on the rotor shaft, one under the engine cover and the other above the inlet opening
2. Two bearings on the feed wheel
3. Two bearings on either side of the feed wheel pivot
1
2
3
4
5
