Bolt torque
When servicing the machine, ensure any bolts you remove are torque to the values listed in the torque table below:
Relative Strength Bolt Marking
4.6
8.8
Maximum Torque
Maximum Torque
Bolt Dia.
Wrench Size
lb ft
Nm
lb ft
Nm
M8
13 mm
7
9.5
18
25
M10
16 mm
14
19
37
50
M12
18 mm
26
35
65
85
M16
24 mm
59
80
159
215
M20
30 mm
118
160
321
435
Specifications
C60RX
General
Length
3850 mm
Width
1800 mm
Height
2100 mm
Weight
1920 kg (2050 kg with winch)
Engine
Make & model
65 HP Kohler liquid cooled, 4 cylinder, turbo charged
Type of fuel
Diesel
Capacities
Fuel tank
75 L
Hydraulic oil tank
100 L
Chassis
Frame description
100 x 50 x 5 mm RHS
Width
1200 mm
Tracked Undercarriage
Speed
5 km/hr max, fully proportional
Track drive
Remote control
Undercarriage material
Rubber
Cutting System
Disc speed
1620 RPM
Disc diameter
800 x 40 mm
Shaft diameter
60 mm
Knives
Four
Feed System
Feed opening
457 x 254 mm (18” x 10”)
Chipping capacity
254 mm (10”)
Feed table height
700 mm
Feed table length
1550 mm
Inlet chute opening
960 x 650 mm
Roller Style
Single roller, spring mounted, 300 mm (12”) diameter
Feed speed range
0-40 m/min (135 f/min), full reverse
Discharge System
Discharge height
2100-2360 mm (adjustable)
Degree of rotation
360°
Transmission System
Belt drive
3x SPB1410
