Grease points
General grease points
The grease points listed below must be greased every 50 operating hours with bearing grease or all-purpose grease:
1. Two bearings on the cutting rotor shaft, one
on the front side of the housing, and one on
the rear:
2. One bearing on the right-hand side of the
feed roller
3. Two bearings on either side of the feed roller
pivot (also referred to as “swing arm”):
1
4
3
2
6
5
7
