24
4. Eight grease nipples on the outlet chute (two
underneath the front edge)
5. One grease nipple on the engine
engagement screw thread: Remove the
‘Engagement Guard’ to reach the grease
nipple by removing the 3 mounting bolts
6. One grease nipple for the feed roller spline
connection:
7. Two grease nipples on the tow coupling
2 nipples
(one on each side)
Engagement guard
Grease nipple
