Specifications
C65
General
Length
4034 mm
Width
1800 mm
Height
2360 mm
Weight
1740 to 1950 kg (depending on options)
Engine
Make & model
64 Hp Deutz F4L2011 4-cylinder, oil-cooled diesel engine
Type of fuel
Diesel
Capacities
Fuel tank
70 L
Hydraulic oil tank
50 L
Chassis
Frame description
100 x 50 x 5 mm RHS
Wheels
15” wheels
Cutting System
Disc speed
1700 RPM
Disc diameter
800 x 40 mm
Shaft diameter
60 mm
Knives
Four
Feed System
Feed opening
457 x 254 mm (18” x 10”)
Chipping capacity
254 mm (10”)
Feed table height
646 mm
Feed table length
1590 mm
Inlet chute opening
1050 x 630 mm
Roller Style
Single roller, spring mounted, 300 mm (12”) diameter
Feed speed range
0-40 m/min (135 f/min), full reverse
Discharge System
Discharge height
2140-2360 mm (adjustable)
Degree of rotation
360°
Transmission System
Belt drive
4x SPB1360
Brakes
Road brakes
Hydraulic road brakes with hand-brake standard
