Product Overview
EN
DPO7000 Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD
14
Display the current sampling rate and storage depth of the analog channel. The
sampling rate and storage depth will change with changes in the horizontal time
base.
7 Horizontal position sign:
Display the current horizontal position.
8 Waveform memory:
Provide a schematic diagram of the position of the waveform in the current screen
in the memory.
9 Trigger location:
Display waveform memory and trigger settings for waveforms on the screen.
10 Trigger source:
Display the current trigger source.
11 Trigger type:
Display the currently selected trigger type and trigger condition settings.
12 Trigger level/threshold level:
The trigger source selection is CH1-CH4, and an appropriate trigger level needs to
be set. Select D0-D15 as the trigger source and set an appropriate threshold level.
The trigger level or trigger threshold will be displayed in the upper right corner.
13 Operation menu:
Press the menu button in the button area to open the corresponding menu.
14 Notification area:
Display icons for time, sound, USB drive, and LAN interface connections.
15 Arbitrary wave generator (option):
Display the open status of any wave generator.
16 Digital channel status area:
Display the current status of the digital channel.
17 Message box:
Display prompt messages.
18 CH4 status label:
Display the status of CH4. Display the disposal gear and offset information of CH4.
Display the current channel settings: channel coupling and bandwidth limitation.
19 CH3 status label:
