Product Overview
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Quick Guide
15
Display the status of CH3. Display the disposal gear and offset information of CH3.
Display the current channel settings: channel coupling and bandwidth limitation.
20、 CH2 status label:
Display the status of CH2. Display the disposal gear and offset information of CH2.
Display the current channel settings: channel coupling and bandwidth limitation.
21、 Analog channel labels/waveforms:
Different channels are identified with different colors, and the channel labels and
waveform colors are consistent.
22、 CH1 status label:
Display the status of CH1. Display the disposal gear and offset information of CH1.
Display the current channel settings: channel coupling and bandwidth limitation.
