Hantek Hantek2000 Series User Manual

input signal.
Functions
Settings
Cursor
Off
Display Format
Set to YT
Horizontal Position
Adjusted
SEC/DIV
Adjusted
Trigger Level
Set to 50%
Trigger Mode
Auto
Trigger Source
Adjusted
Trigger Slope
Adjusted
Trigger Type
Edge
Vertical Bandwidth
Full
Vertical Coupling
DC
VOLTS/DIV
Adjusted
The Auto function examines all channels for signals and displays corresponding
waveforms. Auto determines the trigger source according to the following conditions.
 If multiply channels get signals, the oscilloscope will use the channel with the lowest
frequency signal as the trigger source.
 If no signals are found, the oscilloscope will use the lowest-numbered channel
displayed in Auto Scale as the trigger source.
 If no signals are found and no channels are displayed, the oscilloscope will display and
use Channel 1 as the trigger source.
Default Setting
Long press button, enter Short key setting menu, and select Default. Press
button, pops up the prompt to recall the default settings on the screen, now press F1 to
confirm. The oscilloscope will display the CH1 waveform and remove all the others. Press
F4 to cancel. The table below gives the options, buttons and controls that change settings
at default setup.
Menu or
System
Option, Button or
Knob
Default Setting
Cursor
Type
Off
Source
CH1
Horizontal (amplitude)
±4 div
Vertical (time)
±4 div
Display
Format
YT
Horizontal
Position
0.00s
SEC/DIV
500μs

Hantek Hantek2000 Series Specifications

General

Brand	Hantek
Model	Hantek2000 Series
Category	Measuring Instruments
Language	English
