a) Press the power button to turn on, then press the "DMM" button to enter to the

multimeter function interface;

b) To measure the DC current greater than 200mA, press the up, down, left and right

keys or F1, F2, F3, F4 multi function keys to select "DC A" or "AC A", and insert the

black pen to the input end of the COM banana socket, and insert the red pen into

the input port of the “A” banana socket;

c) To measure the DC current less than 200mA, press the up, down, left and right

keys or F1, F2, F3, F4 multi function keys to select "DC mA" or "AC mA", and insert

the black pen to the input end of the COM banana socket, and insert the red pen

into the input port of the “mA” banana socket.;

d) Connect the red and black forms to the measured point. The current value of the

measured point will be displayed on the screen.

3. Resistance measurement

a) Press the power button to turn on, then press the "DMM" button to enter to the

multimeter function interface;

b) Press the up, down, left and right direction keys or F1, F2, F3, F4 multi-function

keys to select "Ω";

c) Insert the black pen into the input port of the COM banana socket, and insert the

red pen into the input port of the V/Ω/C banana port;

d) Connect the red and black forms to the measured point. The resistance value of

the measured point will be displayed on the screen.

4. Capacitance measurement

e) Press the power button to turn on, then press the "DMM" button to enter to the

multimeter function interface;

f) Press the up, down, left and right direction keys or F1, F2, F3, F4 multi-function

keys to select " ";

g) Insert the black pen into the input port of the COM banana socket, and insert the

red pen into the input port of the V/Ω/C banana port;

h) Connect the red and black forms to the measured point. The capacitance value of

the measured point will be displayed on the screen.

5. Diode measurement

i) Press the power button to turn on, then press the "DMM" button to enter to the

multimeter function interface;

j) Press the up, down, left and right direction keys or F1, F2, F3, F4 multi-function

keys to select " ";

k) Insert the black pen into the input port of the COM banana socket, and insert the

red pen into the input port of the V/Ω/C banana port;

l) Connect the red and black forms to the measured point. The diode value of the

measured point will be displayed on the screen.

6. On-Off measurement
